WCB Eaton Auxiliary Brake — Lip / Edge Seal
Match inner and outer lip seals for Eaton Airflex WCB2 brake cylinders by model and seal position. Standard 24WCB2 and 36WCB2 references use different seal numbers; check the complete code and cylinder configuration.
- Category
- WCB Eaton Auxiliary Brake
- Inquiry details
- Model · Part No. · Quantity
Email2000@pratt-oil.com
WhatsApp+86 159 0808 0040
Selection & Quotation
Send the seal number, inner or outer position, cylinder model, profile, dimensions and quantity. Specify whether you need individual lip seals or a complete seal kit. Preserve leading zeroes and the full suffix.
Part Numbers by Brake Model
Standard-configuration references; confirm the installed assembly before ordering.
| Part number | Component | Brake model reference |
|---|---|---|
000402*0023000402X0023 | Inner lip seal | 124WCB2 / 224WCB2 / 324WCB2 / 424WCB2 |
000402*0024000402X0024 | Outer lip seal | 124WCB2 / 224WCB2 / 324WCB2 / 424WCB2 |
000402*0005000402X0005 | Inner lip seal | 136WCB2 / 236WCB2 / 336WCB2 / 436WCB2 |
000402*0006000402X0006 | Outer lip seal | 136WCB2 / 236WCB2 / 336WCB2 / 436WCB2 |
Number reference: Airflex WCB11070, §§6.1–6.2.
Additional Assembly & Kit References
These tables include several components and kits; they are not a bill of materials for this single product. Match the part number to the drawing and brake configuration.
| No. | Other Technical Specifications | Model | Name | Part Number |
|---|---|---|---|---|
| 1 | Mounting Flange Half Assembly | 513348-01 | Mounting Flange | 513337 |
| Special Bolt & Nut | 000153*0642 / 000153*0685 | |||
| Loctite 596 | 000153*1071 | |||
| Wear Plate | 508459 | |||
| Inner Support Ring | 413107 | |||
| Outer Support Ring | 413108 | |||
| Pressure Plate | 513345 | |||
| 2 | Pressure Plate Half Assembly | 513348-03 | Special Bolt & Nut | 000153*0642 / 000153*0685 |
| Loctite 596 | 000153*1071 | |||
| Wear Plate | 508459 | |||
| Inner Support Ring | 413107 | |||
| Outer Support Ring | 413108 | |||
| Reaction Plate | 513343 | |||
| 3 | Reaction Plate Half Assembly | 513348-02 | Special Bolt & Nut | 000153*0642 / 000153*0685 |
| Loctite 596 | 000153*1071 | |||
| Wear Plate | 508459 | |||
| Inner Support Ring | 413107 | |||
| Outer Support Ring | 413108 | |||
| Friction Disc Core | 510745 | |||
| 4 | Half Friction Disc Assembly | 513964-01 | Friction Disc | 508725 |
| Countersunk Screw | 000294*0407 | |||
| Loctite 596 | 000153*1071 |
| No. | Other Technical Specifications | Model | Name | Part Number |
|---|---|---|---|---|
| 1 | 107821B Friction Disc Kit (Standard) | 124WCB2 Standard | Loctite 262 Thread Adhesive | 000153*1016 |
| Countersunk Screw | 000294*0407 | |||
| Friction Disc | 508725 | |||
| 2 | 107821BA Friction Disc Kit (Standard) | 224WCB2 Standard | Loctite 262 Thread Adhesive | 000153*1016 |
| Countersunk Screw | 000294*0407 | |||
| Friction Disc | 508725 | |||
| Wear Washer | 308396 | |||
| 3 | 107821BB Friction Disc Kit (Standard) | 324WCB2 Standard | Loctite 262 Thread Adhesive | 000153*1016 |
| Countersunk Screw | 000294*0407 | |||
| Friction Disc | 508725 | |||
| Wear Washer | 308396 | |||
| 4 | 107821BC Friction Disc Kit (Standard) | 424WCB2 Standard | Loctite 262 Thread Adhesive | 000153*1016 |
| Countersunk Screw | 000294*0407 | |||
| Friction Disc | 508725 | |||
| Wear Washer | 308396 | |||
| 5 | 107722A Brake Plate Kit (Mounting Flange & Pressure Plate) | 24WCB2 Standard | Special Bolt & Nut | 000153*0642 / 000153*0685 |
| Loctite 596 | 000153*1071 | |||
| Wear Plate | 508459 | |||
| Inner Support Ring | 413107 | |||
| Outer Support Ring | 413108 | |||
| 6 | 107727E Reaction Plate Seal Plate Kit | 24WCB2 Standard | Special Bolt & Nut | 000153*0642 / 000153*0685 |
| Loctite 596 | 000153*1071 | |||
| Wear Plate | 508459 | |||
| Inner Support Ring | 413107 | |||
| Outer Support Ring | 413108 | |||
| 7 | 107727C Cylinder Seal | 24WCB2 Standard | Piston Seal Ring | 000153*1239 |
| Edge Seal (Inner) | 000402*0023 | |||
| Edge Seal (Outer) | 000402*0024 |
| No. | Other Technical Specifications | Model | Name | Part Number |
|---|---|---|---|---|
| 1 | 107822B Friction Disc Kit (Standard) | 136WCB2 | Loctite 262 Thread Adhesive | 000153*1168 |
| Friction Disc | 513658 | |||
| Countersunk Screw | 000294*0407 | |||
| 2 | 107822BA Friction Disc Kit (Standard) | 236WCB2 | Loctite 262 Thread Adhesive | 000153*1168 |
| Friction Disc | 513658 | |||
| Countersunk Screw | 000294*0407 | |||
| Wear Washer | 308397 | |||
| 3 | 107822BB Friction Disc Kit (Standard) | 336WCB2 | Loctite 262 Thread Adhesive | 000153*1168 |
| Friction Disc | 513658 | |||
| Countersunk Screw | 000294*0407 | |||
| Wear Washer | 308397 | |||
| 4 | 107822BC Friction Disc Kit (Standard) | 436WCB2 | Loctite 262 Thread Adhesive | 000153*1168 |
| Friction Disc | 513658 | |||
| Countersunk Screw | 000294*0407 | |||
| Wear Washer | 308397 | |||
| 5 | 107662E Reaction Plate Seal Plate Kit | 36WCB2 | Special Bolt & Nut | 000153*0843 / 000153*0844 |
| Loctite 596 | 000153*1071 | |||
| Wear Plate | 416527 | |||
| Inner Support Ring | 414032-01 | |||
| Outer Support Ring | 414033-01 | |||
| 6 | 107662A Brake Plate Kit (Mounting Flange & Pressure Plate) | 36WCB2 | Special Bolt & Nut | 000153*0843 / 000153*0844 |
| Loctite 596 | 000153*1071 | |||
| Wear Plate | 416527 | |||
| Inner Support Ring | 414032-01 | |||
| Outer Support Ring | 414033-01 | |||
| 7 | 107662C Cylinder Seal | 36WCB2 | Piston Seal Ring | 000153*1239 |
| Edge Seal (Inner) | 000402*0005 | |||
| Edge Seal (Outer) | 000402*0006 |
Request a Quotation
Include the brake model, part number, required quantity and any drawing or product photo references.
